ICED-3 (UK Standard)
| Basic parameters | |
| reader interface | Wigan or OSDP |
| transportation protocol | TCP/IP (100M); RS485 X 2 |
| Audit records (logs)) | 500,000 offline events |
| card capacity | Network: up to 20,000 cards Standalone: up to 2,048 cards |
| network paradigm | Supports 256 access rights; 128 time events and 128 holiday date settings |
